Description

1. PLC (motion controller, Hechuan brand) control system, electrical components are all internationally renowned brands;
2. Adopt man-machine interface operating system, parameter memory, menu management;
3. Empty boxes, empty packages are automatically detected, and cartons that lack packaging and instructions are automatically removed;
4. Automatic shutdown of mechanical overload, fault display, alarm and finished product count;
5. Stable performance and easy to understand operation.

Outstanding Features

The main technical parameters
Cartoning speed: 60-100 boxes/min
Quality requirements: 250-450g/㎡ (depending on the size of the carton)
Size range: (80-210)mm*(35-110)mm*(20-60)mm, special size can be customized
Compressed air working pressure: ≧0.6mpa
Air consumption: 20L/min
Power supply: AC380V /50Hz
Motor power: 15KW
Dimensions: (L x W x H) 4800mm x 1650mm x 2200mm
Machine weight: 2000KG

Specification
